Xiamen Yongxinchang Machinery Equipment Co., Ltd. was established in 1993. It is an enterprise mainly engaged in forklift production, sales, maintenance, leasing, replacement (parts), and tire wholesale. At the same time, it has a professional and stable marketing management team and an engineering and technical team with excellent maintenance skills.Our factory has state-of-the-art equipment for the production and assembly of forklifts, loaders, excavators, and other logistics and transportation equipment.

First 12 3 4 5 6 7 Last

Why Choose Us

Our Service
In addition to the existing products, customers can also customize the appearance of the product, color according to the demand. And add the required configurations according to the customer's needs. In addition to this, we strictly control the quality of our products at every step of the manufacturing process. We offer technical support that is second to none.

Sales Market
We have several specialized sales and service teams that sells to North America, Europe, Asia, Middle East and Africa.

Our Certificate
Strict quality control has always been our pursuit, and our company always believe that the company has gained a large number of customer recognition and satisfaction is inextricably linked to the company's product quality. Our company has strict quality control of our products and has ISO9001, ISO14000 and ISO45001 certificates.

Product Application
Our company's products cover a wide range of applications, which can be used in manufacturing, transportation, logistics and warehousing, electrical machinery, food and beverage, e-commerce, automotive, wholesale and retail, petrochemicals, and more.

Types of Forklift

01/

Industrial Reach Forklift Trucks–Designed for high-rise storage in warehouses, offering variations like stand-up, double-deep, and straddle trucks for different storage needs.

02/

Industrial Counterbalance Forklifts–The most common indoor forklift with front dual forks; three-wheel models offer better maneuverability in narrow aisles.

03/

Rough Terrain Forklifts–Built for outdoor use on uneven terrain with robust tyres, powerful engines, and enhanced stability, ideal for construction sites.

04/

Industrial Side Loader Forklifts–Specialised for handling long, heavy loads in narrow aisles, commonly used in the timber and steel industries.

05/

Telescopic Handler Forklifts–Versatile machines with extendable booms, often used in agriculture and construction, with various attachments for enhanced functionality.

06/

Pedestrian Operated Pallet Trucks–Primarily used in warehouses for moving pallets, with some models capable of lifting loads for stacking.

Technical Parameters of Electric Forklift

Model			CPD45S	CPD50S	CPD60S
Features	Power type		Battery
	Rated load（kg）		4500	5000	6000
	Load center distance（mm）		500	500	600
	Lift height（mm）		3000
	Free lift height（mm）		120	120	150
	Fork size	L×W×T（mm）	1070×150×50		1220×150×60
	Mast tilt angle	Front/Rear	6°/9°
	Minimum turning radius（mm）		2704	2704	2780
	Minimum right angle stacking aisle width（mm）		4300	4300	4350
	Minimum right angle aisle width（mm）		2904	2904	2980
	Minimum ground clearance（mm）		145
	Height of overhead guard（mm）		2285
	Height form seat to overhead guard（mm）		1020
	Overhang (FR)（mm）		578	578	586
Performance	Maximum travel speed	Full load（km/h）	13
		No load（km/h）	14
	Maximum lift speed	Full load（mm/s）	280	280	265
		No load（mm/s）	400	400	380
	Maximum lowering speed	Full load（mm/s）	380	400	430
		No load（mm/s）	350	350	360
	Maximum gradeability（%）		15	15	12
Dimensions	Overall length	Without forks（mm）	3046	3046	3134
	Overall width（mm）		1520
	Mast height at maximum lift (with backrest)（mm）		4270	4270	4280
	Mast lowered height（mm）		2245
Power	Tires	Front wheel	28×12.5-15
		Rear wheel	7.00-12
	Wheelbase（mm）		2000
	Tread	Front wheel/rear wheel（mm）	1200/1130
	Self weight	Without load（kg）	7400	7800	8950
	Battery	Voltage/capacity（V/Ah）	80/700	80/720	80/720
	Motor	Traveling（KW）	11×2
		Lifting（KW）	12×2
	Way of control		AC
	Operating pressure（Mpa）		18.5
	Maximum drawbar pull（KN）		40

Application of Forklift

Lifting and Transporting Materials
The most common use, forklifts facilitate the movement of heavy goods within a site.

Order Picking
In warehouses, forklifts help pick and organise items for delivery, increasing efficiency.

Stacking
Forklifts enable efficient use of vertical space by stacking goods in high shelves, especially in warehouses.

Loading and Unloading
Forklifts simplify the process of loading and unloading trucks, which reduces manual labour and saves time.

Building Site Operations
Forklifts move heavy building materials like bricks, steel and concrete.

Sweeping
With special attachments, forklifts can even be used for sweeping large industrial areas.

Snow Ploughing
With a snow plough attachment, a forklift can clear snow from outdoor spaces in harsh winters.

nstallation Requirements of Forklift

The form and size of the installation

The attachment is installed on the fork carriage of the forklift, and its installation forms are hook-on installation and pin type installation mostly.
For general forklifts, there is an international standards of the height of the fork carriage.
As long as we know the forklift capacity, we will know the mounting class of the attachments needed.

For large tonnage forklift, the fork carriage is often installed in a pin type, so when selecting attachments, it is necessary to provide the drawing of the fork carriage, So that we can design the installation size of attachments accordingly.

Connect the oil pipe of the attachment and the forklift

The attachment relies on the hydraulic system on the forklift to provide power for the it. Therefore, after the attachment is installed on the forklift, the oil circuit needs to be connected next.
The more functions of the attachment, the more additional oil circuits are required for the forklift.

Freight Logistics

productcate-745-863

FAQ

Q: What is the most commonly used forklift?

A: Counterbalance
The Counterbalance is the most common type of forklift. This type of lift has its forks at the front of the machine and is designed with a weight in the back to offset or counter the balance of the load on the front.

Q: What is the rule 3 for forklifts?

A: Use the correct procedure when mounting or dismounting a vehicle or forklift, you must have three points of contact – either two feet and one hand, or two hands and one foot and must be facing the lift truck.

Q: What is a nickname for a forklift?

A: Other common words that are generically used to describe “forklifts” are fork truck, forklift truck, and lifts.

Q: What is the full name of forklift?

A: Powered industrial trucks, commonly called forklifts or lift trucks, are used in many industries, primarily to move materials.

Q: What type of brakes do most forklifts have?

A: Forklifts come equipped with either drum or disc brakes at each wheel site. Drum brakes use brake shoes pressing outward against a spinning surface called a drum; think about rubbing two sticks together to make fire—friction creates friction, slowing the rotation down.

Q: Do forklifts have a clutch?

A: Forklifts have accelerator and brake pedals that operate similarly to these pedals in other vehicles. Some forklifts also have a clutch, which allows shifting into higher forward gears. The inching pedal gives the operator more control of the forklift in tight places.

As one of the most professional forklift manufacturers and suppliers in China, we're featured by quality products and good service. Please rest assured to wholesale customized forklift from our factory.
